Generator Stator for Suzuki VStorm 1000 02-09 / 2012VEHICLE FITMENT2012 Suzuki VStrom 10002009 Suzuki VStrom 10002008 Suzuki VStrom 10002007 Suzuki VStrom 10002006 Suzuki VStrom 10002005 Suzuki VStrom 10002004 Suzuki VStrom 10002003 Suzuki VStrom 10002002 Suzuki VStrom 1000SPECIFICATIONSDimensions:Interior diameter: 54 mmExterior diameter: 119 mmThickness: 28 mmLength of wires stator to grommet: 160 mmLength of wires grommet to plug: 430 mmLength of pickup coil's wire to grommet: 150 mmOther specifications:Number of wires: 5Number of plugs: 2Number of pins: 5Number of poles: 18Wire to wire resistance:Alternator: Black to Black = 0.4 ohms +-20%Alternator: Black to ground = O.LPickup: Blue to Green = 200 ohms +-20%OEM#32101-06G1032101-06G11
| Type | Miscellaneous |
|---|---|
| Part | Generator Stator for Suzuki VStorm 1000 02-09 / 2012 |
| OEM/Part No. | RMS010-107577 |
